Product Overview

132392.00 LEESON 7.5-10HP Single Phase Crop Dryer motor is used on crop dryers with air over/fan on shaft designs.

Part Number:

132392.00

Model/Spec Number:

C182K34NB107

Manufacturer:

Marathon LLC

Technical Details

Specifications

Application	Crop Dryer
Output HP	7.5-10
Output KW	5.6
Output RPM	3450
Frame Size NEMA	182TZ
Voltage	230

Documentation

Product Information Packet

Additional Information

Applications: For use where exposure to water, dust and dirt exists. Ideally suited for use in farm / ag equipment such as feeders, conveyors, fans, grain elevators, silo unloaders, and other demanding farm duty equipment.

Features:

Gasketed capacitor cases and conduit box covers
Meets or exceeds NEMA® service factors
Single phase and three phase designs
Double sealed ball bearings
Double shielded ball bearings on ag fan motors
Condensate drains on general purpose ag motors
Low temperature manual overload protected
High and extra high starting torque ratings
UL recognized component listing and CSA certified

NOTE: This motor is an air-over design and is intended for use in a fan or blower applications where the motor is mounted within the air stream of the fan or blower it is driving: The motor requires this air flow for cooling. Any other use will void the warranty, as the motor will overheat and fail prematurely.
