2HP LEESON 1440RPM 145TC TEFC 3PH 50HZ MOTOR 121277.00
2HP LEESON 1440RPM 145TC TEFC 3PH 50HZ MOTOR 121277.00
Product Overview
121277.00 LEESON 2HP Three Phase Totally Enclosed Fan Cooled 50Hz 12-lead motor is designed specifically for 50Hz service. These motors are intended for equipment built in North America and destined for use in 50Hz service areas around the world.Part Number:
121277.00Manufacturer:
Leeson ObsoleteManufacturer Part Number:
C145T14FC5Technical Details
Specifications
Brand | Leeson |
Application | General Purpose |
Output HP | 2 |
Output KW | 1.5 |
Output RPM | 1440 |
Frame Size NEMA | 145TC |
Documentation
Additional Information
LEESON Three Phase NEMA Frame Totally Enclosed Fan Cooled Motors are designed to North American performance standards. 12-lead motor designed specifically for 50 Hz. Suitable for 220/380VAC, 50 Hz, or 440VAC, 50Hz, three phase power. Torques exceed NEMA performance standards for design B motors and produce the full rated horsepower at 50 Hz speeds. Construction meets IEC, IP54 degree of protection standards and utilized external fan cooling (IEC cooling method IC41). Gasketed conduit box if in the North American standardized F1 location, with leads.
