1/3HP WEG 1730RPM W56 TEFC 3PH BRAKE MOTOR .3318ES3EBMW56-S

Picture is for reference only.

Part Number:

.3318ES3EBMW56-S

Model/Spec Number:

14593614

Manufacturer:

WEG

.3318ES3EBMW56-S WEG 1/3HP Three Phase Rolled Steel Brakemotor consists of an induction motor coupled to a solenoid actuated brake. Brake is of sturdy construction with few moving parts which guarantees long durability and minimum maintenance.

Ordering Notes

Factory lead times may apply for this product. Contact our Sales Team for delivery times.

MSRP: $977.00

Regular Price

USD

869

QTY

Shipping Details

Weight:

29 lbs

Dimensions:

16 x 21 x 16 inches

HS Code:

8501.52.4000

UPC:

7909492492610

Technical Details

Specifications

Brand:	WEG
Application:	Brakemotor
Output HP:	1/3
Output KW:	0.25
Output RPM:	1730//1400
Frame Size NEMA:	W56
Mount NEMA:	With Base
Enclosure NEMA:	IC411 - TEFC
Enclosure IEC:	IP55
Voltage:	208-230/460//190-220/380-415

Documentation

Product Information Packet

WEG 3PH Rolled Steel Brakemotor Brochure

Additional Information

WEG Three Phase Rolled Steel Brakemotor consists of an induction motor coupled to a solenoid actuated brake. Brake is of sturdy construction with few moving parts which guarantees long durability and minimum maintenance.
