3HP MARATHON 3500RPM 90L TEFC IP55 3PH B3 GLOBETROTTER IEC MOTOR R321A

3HP MARATHON 3500RPM 90L TEFC IP55 3PH B3 GLOBETROTTER IEC MOTOR R321A

280S copy.jpg

Part Number:

R321A

Model/Spec Number:

090LT34FH6301

Manufacturer:

Regal IEC
R321A MARATHON 3HP Globetrotter B3 IEC Motor is designed for use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

45 lbs

Dimensions:

12 x 18 x 14 inches

HS Code:

8501.52.4000

UPC:

722856026507

Technical Details

Brand:

Marathon

Application:

General Purpose

Output HP:

3

Output KW:

2.2

Output RPM:

3500//2875

Frame Size IEC:

90L

Mount IEC:

B3 Foot Mount

Enclosure NEMA:

TEFC

Enclosure IEC:

IP55

IEC Shaft Dia.:

24mm

Product Information Packet

APPLICATIONS: For use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards. The TERRAMAX is not only designed to International standards but meets NEMA performance and efficiency standards making it suitable for requirements worldwide.

FEATURES:

  • Non-Removable Base
  • Meets IE3 European and NEMA premium efficiency standards
  • 60/50 Hz interchangeability
  • UL listed and CSA certified
  • Wye Start-Delta Run as optional feature above 3kW
  • Meets IEEE45, IEC60092 & USCG CFR46 Marine Duty
  • IEC design “N” with NEMA “B” torques
  • Meets IEC 34 electrical standards
  • Meets IEC 72 dimensions and tolerances
  • CE marked
