1/2HP MARATHON 1695RPM 71 B3/B5 IP55 3PH GLOBETROTTER IEC MOTOR R387

1/2HP MARATHON 1695RPM 71 B3/B5 IP55 3PH GLOBETROTTER IEC MOTOR R387

B3-B5 ALUMINUM.jpg

Part Number:

R387

Model/Spec Number:

071T17FH5508

Manufacturer:

Regal IEC
R387 MARATHON 1/2HP Globetrotter B3/B5 IEC Metric Motor is designed for use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

21 lbs

Dimensions:

10 x 14 x 12 inches

HS Code:

8501.51.4040

UPC:

722856027290

Technical Details

Brand:

Marathon

Application:

General Purpose

Output HP:

1/2

Output KW:

0.37

Output RPM:

1695//1380

Frame Size IEC:

71

Mount IEC:

B3/B5 Foot/Flange

Enclosure NEMA:

TEFC

Enclosure IEC:

IP55

IEC Shaft Dia.:

14mm

Product Information Packet

APPLICATIONS: For use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards. The Globetrotter is not only designed to International standards but meets NEMA performance and efficiency standards making it suitable for requirements worldwide.

FEATURES:

  • B5 flange/base mounting
  • Meets IE3 European and NEMA Premium® efficiencies
  • MAX GUARD® Class F Insulation, Class B rise @ rated KW
  • Rotatable/Removable Base (63-90 frame)
  • Top Mounted/Oversized gasketed terminal box
  • Meets IEEE45, IEC60092 & USCG CFR46 Marine Duty (Below Deck)
  • 1.15 Service Factor on 60 Hz sine wave, 1.0 SF or VFD
  • IEC Design “N” with NEMA “B” Torques
  • Terminal Blocks, Stud Type, Zero Creepage
  • Meets IEC 34 electrical standards
  • Meets IEC 72 dimensions and tolerances
  • CE Marked
