1HP MARATHON 1155RPM 90S TEFC IP55 3PH B3 GLOBETROTTER IEC MOTOR R314A

1HP MARATHON 1155RPM 90S TEFC IP55 3PH B3 GLOBETROTTER IEC MOTOR R314A


Part Number:

R314A

Model/Spec Number:

090ST11FH6376

Manufacturer:

Regal Rexnord Commercial

Manufacturer Part Number:

90ST11FH6376A
R314A MARATHON 1HP Globetrotter B3 IEC Motor is designed for use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards.

Ordering Notes

Discontinued item with limited availability, subject to prior sale. Non-Returnable

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

43 lbs

Dimensions:

12 x 17 x 13 inches

HS Code:

8501.52.4000

UPC:

722856026286

Technical Details

Brand:

Marathon

Application:

General Purpose

Output HP:

1

Output KW:

0.75

Output RPM:

1155//945

Frame Size IEC:

90S

Mount IEC:

B3 Foot Mount

Enclosure NEMA:

TEFC

Enclosure IEC:

IP55

IEC Shaft Dia.:

25.4

Product Information Packet

APPLICATIONS: For use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards. The TERRAMAX is not only designed to International standards but meets NEMA performance and efficiency standards making it suitable for requirements worldwide.

FEATURES:

  • Non-Removable Base
  • Meets IE3 European and NEMA premium efficiency standards
  • 60/50 Hz interchangeability
  • UL listed and CSA certified
  • Wye Start-Delta Run as optional feature above 3kW
  • Meets IEEE45, IEC60092 & USCG CFR46 Marine Duty
  • IEC design “N” with NEMA “B” torques
  • Meets IEC 34 electrical standards
  • Meets IEC 72 dimensions and tolerances
  • CE marked
