LEESON Three Phase WASHGUARD Extreme Duck Ultra Stainless Motors with SGR

LEESON Three Phase Extreme Duck Ultra Motor with Shaft Grounding Ring designed for appications involving speed control with AC inverters. The shaft grounding ring protects bearings from damage by stray voltages. These motors are built to withstand the extreme washdown and sanitation requirements of the food processing, pharmaceutical, packaging, and bevarage industries. 300-Series Stainless Steel used on all exterior surfaces gives ideal protection against severe chemical-processing applications and frequent washdown processes using salt water, nitric acids and solvents.

Features:

• IP69K enclosure protection
• All exterior components are 300-Series stainless steel
• NEMA Premium efficiency rating - 1HP and higher
• IRIS Inverter rated insulation system - 1HP and higher
• Unique “Q-CAR” rotor/cartridge seal system designed for quick access to the interior of the motor
• "HS2" Hydro-sealed system eliminates the need for drain plugs and breathers
• Fully encapsulated
• Full fact nameplate etched in frame
• Double sealed ball bearings
• Viton sealing components
• Color-coded, non-wicking lead wires with chemical and abrasion resistant markers
• Motors are UL component recognized – file number E57948, guide number PRGY2
• CSA Energy Efficiency Verification Program, report number EEV 78720-1
• Construction is CSA Certified for safety, report number LR33543
• Listed under BISSC authorization number 769
