KBIC Signal Isolator (SI-5) 9443

KBIC KB Electronics Signal Isolator (SI-5) 9443

Part Number:

KB9443

Model/Spec Number:

KBIC SI-5

Manufacturer:

KB Electronics

Manufacturer Part Number:

9443

KBIC KB Electronics 9443 Signal Isolator (SI-5) converts standard KBIC and KBMM controls to an isolated input.

Technical Details

Specifications

Series:	KBIC
Enclosure IP:	IP20
Signal Isolator:	(SI-5)
Brand:	KB Electronics
Run/Stop:	(SI-5)

Documentation

KBIC Data Sheet

Additional Information

KBIC Signal Isolator (SI-5) converts standard KBIC® control to an isolated input. By using external resistors, the input signal can be changed to 0-100VDC, 0-200VDC and 4-20mA. The output voltage is 0-10VDC which can be rescaled via the built-in Min and Max trimpots. Selectable AC line jumpers allow the SI-5 and SI-6 to be used either with 115 or 230VAC controls. Installation is made by simply mating the unit to the speed control via the built-in quick-connect terminals.
