Product Overview

KBIC BTB KB Electronics 9884 Barrier Terminal Board easily convert a standard control with quick-connect terminals to barrier terminals. Provision is made for AC line and armature fusing. The Barrier Terminal Board installs directly over the control by mating the Q-D terminals.

Part Number:

KB9884

Model/Spec Number:

KBIC BTB

Manufacturer:

KB Electronics

Manufacturer Part Number:

9884

Technical Details

Specifications

Series	KBIC
Brand	KB Electronics

Documentation

KBIC Data Sheet

Additional Information

KBIC Barrier Terminal Board easily convert a standard control with quick-connect terminals to barrier terminals. Provision is made for AC line and armature fusing. The Barrier Terminal Board installs directly over the control by mating the Q-D terminals. A separate .110” jumper wire can be used to connect to the I1 Inhibit terminal or, on the KBMM™, to the T or B terminals which are used for tach feedback. (Refer to KBMM™ Instruction Manual.) Fuses supplied separately.
