DART CONTROLS CF SERIES SPEED PICKUP KIT CF-H60

DART CONTROLS CF SERIES SPEED PICKUP KIT for applications where location of an accessible shaft is difficult or more pulses per revolution are needed. With this c-face motor mounted hall-effect pickup, customers are able to monitor actual motor speed, verify motor rotation, and determine the location of motor driven devices such as spray application heads and material handling system carriers. Signals are fed to closed loop motor drives, PLCs, and SCADA systems. For indoor use only.

Features:

• Kit consists of motor face ring, mounting hardware, and sensing disk (shaft mount)
• Molded sensing disk impervious to dust, oil, and water
• Supply voltage: +4.5 to +24VDC
• Output connections: 3 wires
• Ambient temperature: -40°C to +125°C
• NPN open collector output sinks 20mA max
