1/3HP WEG 3485RPM 56J TEFC 3PH JET PUMP MOTOR .3336ES3EJP56J-S

1/3HP WEG 3485RPM 56J TEFC 3PH JET PUMP MOTOR .3336ES3EJP56J-S

Picture is for reference only.

Part Number:

.3336ES3EJP56J-S

Model/Spec Number:

14804147

Manufacturer:

WEG
.3336ES3EJP56J-S WEG 1/3HP Three Phase Jet Pump Motor has the torque and durability for the toughest commercial applications. Available with or without base and in "J" and "C" configurations.
MSRP: $259.00

Regular Price

USD

$

230

51

QTY
Login to View Discounts

Weight:

21 lbs

Dimensions:

17 x 18 x 17 inches

HS Code:

8501.51.4000

UPC:

7900060751191

Technical Details

Brand:

WEG

Application:

Jet Pump

Output HP:

1/3

Output KW:

0.25

Output RPM:

3485

Frame Size NEMA:

56J

Mount NEMA:

C Face With Base

Enclosure NEMA:

TEFC

Enclosure IEC:

IP55

Voltage:

208-230/460//190-220/380-415

Product Information Packet

WEG Three Phase Jet Pump Motors have the torque and durability for the toughest commercial applications. Available with or without base and in “J” and “C” configurations.

Features:

  • 5/8" Threaded output shaft
  • Stainless steel shaft end
  • C Face mounting provisions with base
  • Insulation Class F
  • NEMA Service Factor
