7.5HP WEG 1760RPM 213/5T ODP 1PH MOTOR 00718OS1F215T
7.5HP WEG 1760RPM 213/5T ODP 1PH MOTOR 00718OS1F215T
Picture is for reference only.
Part Number:
00718OS1F215TModel/Spec Number:
10321749Manufacturer:
Weg ObsoleteClick below to request an agent review potential options.
Shipping Details
Weight:
129 lbsDimensions:
20 x 26 x 170 inchesHS Code:
8501.40.6040UPC:
7890208786348Technical Details
Specifications
Application: | General Purpose |
Output HP: | 7.5 |
Output KW: | 5.5 |
Output RPM: | 1760 |
Frame NEMA: | 213/5T |
Mount NEMA: | Base Mount |
Enclosure NEMA: | ODP |
Enclosure IEC: | IP21 |
Voltage: | 230/460 |
Frequency (Hz): | 60 |
Documentation
Additional Information
WEG Single Phase General Purpose Motor is the perfect option for applications that require robustness, low weight, and high performance in a single product. These rolled steel motors offer good thermal performance and easy installation and maintenance. Because of their high starting torque, they are particularly well suited for heavy starting loads.
Features:
- Ball bearings
- Class F insulation
- F1 mounted
- V-ring seals
