3HP WEG 1765RPM 182/4T ODP 1PH MOTOR 00318OS1CCDOL184T-S
3HP WEG 1765RPM 182/4T ODP 1PH MOTOR 00318OS1CCDOL184T-S
Part Number:
00318OS1CCDOL184T-SModel/Spec Number:
15761864Manufacturer:
WEGFactory lead times may apply for this product. Contact our Sales Team for delivery times.
Regular Price
USD
$
611
43
Shipping Details
Weight:
78 lbsDimensions:
18 x 22 x 18 inchesHS Code:
8501.40.6040UPC:
7909712613238Technical Details
Specifications
Application: | General Purpose |
Output HP: | 3 |
Output KW: | 2.2 |
Output RPM: | 1765 |
Frame NEMA: | 182/4T |
Mount NEMA: | Base Mount |
Enclosure NEMA: | IC01 - ODP |
Enclosure IEC: | IP21 |
Voltage: | 208-230 |
Frequency (Hz): | 60 |
Documentation
Additional Information
WEG Single Phase General Purpose Rolled Steel Motor is the perfect option for applications that require robustness, low weight, and high performance in a single product. These rolled steel motors offer good thermal performance and easy installation and maintenance. Because of their high starting torque, they are particularly well suited for heavy starting loads.
Features:
- Ball bearings
- Class F insulation
- V-ring seals
- NPT Threaded holes in terminal box
Factory lead times may apply for this product. Contact our Sales Team for delivery times.
