STEARNS 81000 Series Genuine Replacement Parts

/

125FT-LB STEARNS 81/82000 Series AC Support Plate Assembly 54220710009

125FT-LB STEARNS 81/82000 Series AC Support Plate Assembly 54220710009

Picture is for reference only.

Part Number:

54220710009

Model/Spec Number:

5-42-2071-00-09

Manufacturer:

Stearns Parts
5-42-2071-00-09 125FT-LB STEARNS 81/82000 Series AC Support Plate Assembly

Ordering Notes

Non Returnable. STEARNS Products are normally stocked, but 10-15 day lead times may apply. Please do not order expedited shipping without contacting our sales office for stock and availability.

Informational Item

This is item is for informational purposes only and cannot be purchased. Please contact customer service for more details.

Weight:

35 lbs

Dimensions:

18 x 18 x 6 inches

HS Code:

8505.90.7501

UPC:

662327210199

Technical Details

Stearns Series:

81000/82000

Static Torque Lb.-ft.:

125

Coil Size:

#9

Enclosure NEMA:

NEMA4, NEMA2

Enclosure IEC:

IP23, IP54

Coil Hz:

60//50

Endplate Material:

Cast Iron

Mount Orientation:

Horizontal/Vertical

Application:

General Purpose

81000 Product-Packet

Proper Installation of STEARNS support plate assembly: Reset Lever Arm on Support Plate
Image for STEARNS 81000/82000 Series Pressure Spring Green 970460100

STEARNS 81000/82000 Series Pressure Spring Green 970460100

MSRP: $148.65

Regular Price

$

90

30

Image for #9 STEARNS Injection Molded 230/460VAC Class-B Coil 596690933

#9 STEARNS Injection Molded 230/460VAC Class-B Coil 596690933

Image for #9 STEARNS Epoxy Encapsulated Class-H 230/460VAC Coil 596690905

#9 STEARNS Epoxy Encapsulated Class-H 230/460VAC Coil 596690905

MSRP: $2,738.27

Regular Price

$

1,580

80

Image for #9 STEARNS Epoxy Encapsulated Class-H 460VAC Coil 596690405

#9 STEARNS Epoxy Encapsulated Class-H 460VAC Coil 596690405

MSRP: $2,208.55

Regular Price

$

1,275

04

Image for STEARNS 81000 Series Friction Disc 566841400

STEARNS 81000 Series Friction Disc 566841400

MSRP: $504.95

Regular Price

$

288

03

Image for STEARNS 81000 Series 3-TAB Vertical/Horizontal Stationary Disc 800321101

STEARNS 81000 Series 3-TAB Vertical/Horizontal Stationary Disc 800321101

MSRP: $353.51

Regular Price

$

201

64

Image for #8 & #9 STEARNS Plastic Plunger Guide (EACH) 808255300

#8 & #9 STEARNS Plastic Plunger Guide (EACH) 808255300

MSRP: $40.11

Regular Price

$

33

22

Image for #8 & #9 STEARNS Bronze Plunger Guide (EACH) 808258100

#8 & #9 STEARNS Bronze Plunger Guide (EACH) 808258100

MSRP: $82.58

Regular Price

$

54

98
