Stearns Brakes

/

Stearns Nema Mounting Brakes

/

STEARNS 87600 Series NEMA Brakes

/

75FT-LB STEARNS 87600 Navy Series IP54 460VAC Brake 108766200HLB

75FT-LB STEARNS 87600 Navy Series IP54 460VAC Brake 108766200HLB


Product Overview

1-087-662-00-HLB STEARNS 75FT-LB 87600 Series IP54 Brake is designed to Military Specification for many shipboard and severe duty applications.

Part Number:

108766200HLB

Model/Spec Number:

1-087-662-00-HLB

Manufacturer:

Stearns Brakes

Manufacturer Part Number:

108766200HLB

Technical Details

Stearns Series

87600

Static Torque Lb.-ft.

75

Coil Size

#8

Enclosure NEMA

NEMA4

Enclosure IEC

IP54

Hub Bore Dia.

H: 1-5/8"

STEARNS 87600 Series NEMA Navy Duty Mounting Brakes are designed for industrial marine applications with high performance in a compact design. Features include ductile-iron enclosure, brass stationary and pressure plates disc packs. Mill spec coatings with SAB Style Power released spring set brake.

FEATURES:

  • Suitable for many shipboard and severe duty applications
  • Maintained manual release with auto rest
  • Self-adjusting for wear
  • Brass pressure plate and stationary disc
  • Coil Insulation: Class H Encapsulated
  • ABS Type Approval Certified

Related Items

Image for #8 STEARNS Epoxy Encapsulated Class-H 460VAC Coil 596680405

#8 STEARNS Epoxy Encapsulated Class-H 460VAC Coil 596680405

MSRP: $1,506.58

Regular Price

$

838

00

Image for STEARNS 87600 Navy Series #8 AC Solenoid Assembly 512058300

STEARNS 87600 Navy Series #8 AC Solenoid Assembly 512058300

MSRP: $2,415.01

Regular Price

$

1,297

43

Image for STEARNS 87000 Series Standard Duty 24 Spline Friction Disc 566847800

STEARNS 87000 Series Standard Duty 24 Spline Friction Disc 566847800

MSRP: $525.00

Regular Price

$

284

93

Image for STEARNS 87000 Series Bronze Horizontal/Vertical 1-Stationary Disc 800370401

STEARNS 87000 Series Bronze Horizontal/Vertical 1-Stationary Disc 800370401

MSRP: $1,129.05

Regular Price

$

610

88

Image for 35, 75, 105FT-LB STEARNS 87600 Navy Series AC Support Plate 54271170006

35, 75, 105FT-LB STEARNS 87600 Navy Series AC Support Plate 54271170006

MSRP: $5,752.60

Regular Price

$

3,104

70

Image for STEARNS 87000 Series Horizontal Bronze Pressure Plate 800570301

STEARNS 87000 Series Horizontal Bronze Pressure Plate 800570301

MSRP: $1,090.12

Regular Price

$

589

35

Image for 50-75FT-LB STEARNS 87600 Series IP54 2-Disc Endplate 80027860130B

50-75FT-LB STEARNS 87600 Series IP54 2-Disc Endplate 80027860130B

MSRP: $5,452.94

Regular Price

$

2,929

54

Image for STEARNS 87600 Navy Series 2-Disc Hub 1-5/8" Bore 51671080001H
