6FT-LB STEARNS 87000 Series NEMA2 115VAC Brake 1087001H0DBF

6FT-LB STEARNS 87000 Series NEMA2 115VAC Brake 1087001H0DBF

87000-IP23 Brake.jpg
Picture is for reference only.

Part Number:

1087001H0DBF

Model/Spec Number:

1-087-001-H0-DBF

Manufacturer:

Stearns Obsolete
1-087-001-H0-DBF STEARNS 6 Ft-LB NEMA2 Mounting Brake is designed for industrial applications with high performance in a compact lightweight design.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

22 lbs

Dimensions:

16 x 14 x 12 inches

HS Code:

8505.20.0000

UPC:

793699087888

Technical Details

Stearns Series:

87000

Static Torque Lb.-ft.:

50

Coil Size:

#6

Enclosure NEMA:

NEMA2

Enclosure IEC:

IP23

Hub Bore Dia.:

D: 7/8"

Coil Voltage AC:

115//95

Coil Hz:

60//50

Release:

Pull Release

Endplate Material:

Aluminum

87000 Product Packet

APPLICATIONS: NEMA Motor Mounting Brake

FEATURES:

  • Die cast aluminum endplate with stamped steel housing
  • Self-Adjusting Design
  • Lead Wire Length: 24 inches
  • Maximum Speed: Horizontal 4000 rpm, Vertical 3600RPM Mod Required
  • Coil Insulation: Class H Standard
  • Certified: CSA File LR-6254
  • ABS Type Approval Certified
