75HP MARATHON 3575RPM 250M 3PH B3 TERRAMAX IEC MOTOR R503A

75HP MARATHON 3575RPM 250M 3PH B3 TERRAMAX IEC MOTOR R503A

200L B3.jpg

Part Number:

R503A

Model/Spec Number:

TCA0551AE211GAA009

Manufacturer:

Marathon LLC
R503A MARATHON 75HP TERRAMAX B3 IEC Metric Motor is designed for use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards.
MSRP: $14,422.00

Regular Price

USD

$

9,951

18

QTY
Login to View Discounts

Free No Rush Shipping

Weight:

1,136 lbs

Dimensions:

44 x 39 x 42 inches

HS Code:

8501.52.0000

UPC:

722856074959

Technical Details

Brand:

Marathon

Application:

General Purpose

Output HP:

75//60

Output KW:

55.0//45.0

Output RPM:

3575//2980

Frame Size IEC:

250M

Mount IEC:

B3 Foot Mount

Enclosure NEMA:

TEFC

Enclosure IEC:

IP55

IEC Shaft Dia.:

65mm

Product Information Packet

APPLICATIONS: For use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards. The TERRAMAX is not only designed to International standards but meets NEMA performance and efficiency standards making it suitable for requirements worldwide.

FEATURES:

  • Non-Removable Base
  • Meets IE3 European and NEMA premium efficiency standards
  • 60/50 Hz interchangeability
  • UL listed and CSA certified
  • Wye Start-Delta Run as optional feature above 3kW
  • Meets IEEE45, IEC60092 & USCG CFR46 Marine Duty
  • IEC design “N” with NEMA “B” torques
  • Meets IEC 34 electrical standards
  • Meets IEC 72 dimensions and tolerances
  • CE marked
