1HP LEESON 1740RPM 80 TEFC IP55 3PH B3 IEC MOTOR R313A

1HP LEESON 1740RPM 80 TEFC IP55 3PH B3 IEC MOTOR R313A

Picture is for reference only.

Part Number:

R313A

Model/Spec Number:

080T17FH15327

Manufacturer:

Regal IEC
R313A LEESON 1HP B3 IEC Motor is designed for use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards.

Ordering Notes

Non returnable. Use the Data-Sheet provided to confirm product specs.

MSRP: $1,335.00

Regular Price

USD

$

469

00

QTY
Login to View Discounts

Weight:

32 lbs

Dimensions:

12 x 17 x 13 inches

HS Code:

8501.52.4000

UPC:

722856054333

Technical Details

Brand:

Leeson

Application:

General Purpose

Output HP:

1

Output KW:

0.75

Output RPM:

1740//1420

Frame Size IEC:

80

Mount IEC:

B3 Foot Mount

Enclosure NEMA:

TEFC

Enclosure IEC:

IP55

IEC Shaft Dia.:

19mm

Product Packet

APPLICATIONS: For use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards. The Globetrotter is not only designed to International standards but meets NEMA performance and efficiency standards making it suitable for requirements worldwide.

FEATURES:

  • Meets IE3 European and NEMA Premium® efficiencies
  • MAX GUARD® Class F Insulation, Class B rise @ rated KW
  • Rotatable/Removable Base (63-90 frame)
  • Top Mounted/Oversized gasketed terminal box
  • 1.15 Service Factor on 60 Hz sine wave, 1.0 SF or VFD
  • IEC Design “N” with NEMA “B” Torques
  • Terminal Blocks, Stud Type, Zero Creepage
  • Meets IEC 34 electrical standards
  • Meets IEC 72 dimensions and tolerances
  • CE Marked
Image for 1HP Worldwide 1800RPM 80 Frame B3 IP55 3PH Aluminum IEC Motor IEC1-18-80

1HP Worldwide 1800RPM 80 Frame B3 IP55 3PH Aluminum IEC Motor IEC1-18-80

MSRP: $674.59

Regular Price

$

359

75

Image for 80 FRAME LEESON B14 IEC Flange Mounting Kit A563

80 FRAME LEESON B14 IEC Flange Mounting Kit A563

MSRP: $36.00

Regular Price

$

32

00

Image for 80 FRAME LEESON B5 IEC Flange Mounting Kit A571
