GT3428A MARATHON 25HP 3PH CLOSE COUPLED PUMP MOTOR 284TTFCD6037

25HP MARATHON 1775RPM 284JP TEFC 3PH PUMP MOTOR GT3428A

Part Number:

GT3428A

Model/Spec Number:

284TTFCD6037

Manufacturer:

Marathon LLC

GT3428A MARATHON 25HP Three Phase TEFC Globetrotter Premium Close-Coupled JP Pump Motor designed for use with close-coupled pumps where the pump impeller is mounted directly on the motor shaft in environments that are relatively clean and dry.

Technical Details

Specifications

Brand:	Marathon
Application:	Closed Coupled
Output HP:	25//20
Output KW:	18.7//14.9
Output RPM:	1775//1476
Frame Size NEMA:	284JP
Mount NEMA:	C Face With Base
Enclosure NEMA:	TEFC
Enclosure IEC:	IP55
Voltage:	230/460//190/380

Documentation

Product Information Packet

Additional Information

APPLICATIONS: Close-coupled pump where the pump impeller is mounted directly on the motor shaft in environments that are relatively clean and dry.

FEATURES:

Meets or exceeds NEMA Premium® efficiency
Model is in compliance with EISA2007
Class F Insulation
Dual frame mounting holes

This product must be installed and serviced by a qualified technician, electrician, or electrical maintenance person familiar with its operation and the hazards involved. Proper installation, which includes electrical connections, fusing or other current protection, and grounding, can reduce the chance of electrical shocks, and fires, in this product or products used with this product, such as electric motors, switches, coils, solenoids, and relays. Do not use this product in an explosion-proof application.
