3HP MARATHON 1755RPM 182TC TENV 3PH VECTOR DUTY MOTOR Y541A

Product Overview

Y541A MARATHON 3HP Three Phase Black Max Inverter (Vector) Duty motor is designed for use with material handling, machine tools, conveyors, crane and hoist, metal processing, test stands, pumps compressors, textile processing, and other industrial machinery installed in dusty or dirty environments.

Part Number:

Y541A

Model/Spec Number:

182THTY7726

Manufacturer:

Marathon LLC

Manufacturer Part Number:

Y541A

Technical Details

Specifications

Brand	Marathon
Application	Vector Duty
Output HP	3
Output KW	2.2
Output RPM	1755
Frame Size NEMA	182TC

Documentation

Product Information Packet

Additional Information

APPLICATIONS: Designed for inverter or vector applications where up to a 1000:1 Constant Torque speed range is required. Typical uses include: material handling, machine tools, conveyors, crane and hoist, metal processing, test stands, pumps compressors, textile processing, and other industrial machinery installed in dusty or dirty environments.

FEATURES:

MAX GUARD® Class F insulation system
Constant Torque operation from 0 to base speed on Vector Drive
Constant Horsepower operation up to twice base RPM
Continuous duty at 40ºC ambient
Optimized for operation with IGBT inverter (NEMA Design A)
Normally closed thermostats (one per phase, Class F)
Ball Bearings
Encoder and brake provisions included on opposite drive end (maximum 10 lb-ft brake)
UL Recognized, CSA Certified, and CE Mark
Three year warranty
