10HP MARATHON 880RPM 284T TEAO 460V 3PH KILN DUTY MOTOR S517

APPLICATIONS: Designed for fans in kilns and other high ambient environments where long life and high efficiency is desired. These TEAO motors must be mounted within the airstream for proper cooling. Suitable for use on variable frequency drives.

FEATURES:

• Blue Chip Severe Duty quality, 100% cast iron construction for rigidity and reduced vibration
• Internal and external epoxy paint
• CR²⁰⁰ Corona resistant magnet wire
• Class H insulation system
• Normally closed thermostats (one phase, class H)
• Heat stabilized ball bearings and high temperature grease
• Suitable for inverter use for 20:1 Variable torque with 1.0 S.F. in 90 degree C ambient
• Extended grease tubes, re-greaseable in service
• 8 Foot Leads
• UL Recognized and CSA Certified

This product must be installed and serviced by a qualified technician, electrician, or electrical maintenance person familiar with its operation and the hazards involved. Proper installation, which includes electrical connections, fusing or other current protection, and grounding, can reduce the chance of electrical shocks, and fires, in this product or products used with this product, such as electric motors, switches, coils, solenoids, and relays. Do not use this product in an explosion-proof application.
