1HP MARATHON 3420RPM 80 TEFC IP55 3PH B3 GLOBETROTTER IEC MOTOR R312A
1HP MARATHON 3420RPM 80 TEFC IP55 3PH B3 GLOBETROTTER IEC MOTOR R312A
Part Number:
R312AModel/Spec Number:
080T34FH15301Manufacturer:
Regal IECDiscontinued item with limited availability. Please call for stock status before ordering. Non-Returnable
Shipping Details
Weight:
27 lbsDimensions:
12 x 16 x 13 inchesHS Code:
8501.52.4000UPC:
722856054326Technical Details
Specifications
Brand: | Marathon |
Application: | General Purpose |
Output HP: | 1 |
Output KW: | 0.75 |
Output RPM: | 3420//2840 |
Frame Size IEC: | 80 |
Mount IEC: | B3 Foot Mount |
Enclosure NEMA: | TEFC |
Enclosure IEC: | IP55 |
IEC Shaft Dia.: | 19mm |
Documentation
Additional Information
APPLICATIONS: For use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards. The TERRAMAX is not only designed to International standards but meets NEMA performance and efficiency standards making it suitable for requirements worldwide.
FEATURES:
- Non-Removable Base
- Meets IE3 European and NEMA premium efficiency standards
- 60/50 Hz interchangeability
- UL listed and CSA certified
- Wye Start-Delta Run as optional feature above 3kW
- Meets IEEE45, IEC60092 & USCG CFR46 Marine Duty
- IEC design “N” with NEMA “B” torques
- Meets IEC 34 electrical standards
- Meets IEC 72 dimensions and tolerances
- CE marked
