1/3HP MARATHON 1130RPM 80TZ TEFC IP55 3PH B3 GLOBETROTTER IEC MOTOR R305

1/3HP MARATHON 1130RPM 80TZ TEFC IP55 3PH B3 GLOBETROTTER IEC MOTOR R305


Part Number:

R305

Model/Spec Number:

080T11FH5376

Manufacturer:

Regal IEC
R305 MARATHON 1/3HP Globetrotter B3 IEC Motor is designed for use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards.

Ordering Notes

This Marathon motor is being discontinued and quantities are limited.  Please call for availability before ordering. Non-Returnable.

Item Discontinued

Click below to request an agent review potential options.

Weight:

24 lbs

Dimensions:

10 x 16 x 12 inches

HS Code:

8501.51.4040

UPC:

722856026194

Technical Details

Brand:

Marathon

Application:

General Purpose

Output HP:

1/3

Output KW:

0.25

Output RPM:

1130//915

Frame Size IEC:

80TZ

Mount IEC:

B3 Foot Mount

Enclosure NEMA:

TEFC

Enclosure IEC:

IP55

IEC Shaft Dia.:

19mm

Product Information Packet

APPLICATIONS: For use on fans, pumps, compressors, conveyors, and other equipment requiring IEC dimensions and electrical standards. The Globetrotter is not only designed to International standards but meets NEMA performance and efficiency standards making it suitable for requirements worldwide.

FEATURES:

  • Meets IE3 European and NEMA Premium® efficiencies
  • MAX GUARD® Class F Insulation, Class B rise @ rated KW
  • Rotatable/Removable Base (63-90 frame)
  • Top Mounted/Oversized gasketed terminal box
  • Meets IEEE45, IEC60092 & USCG CFR46 Marine Duty (Below Deck)
  • 1.15 Service Factor on 60 Hz sine wave, 1.0 SF or VFD
  • IEC Design “N” with NEMA “B” Torques
  • Terminal Blocks, Stud Type, Zero Creepage
  • Meets IEC 34 electrical standards
  • Meets IEC 72 dimensions and tolerances
  • CE Marked
Image for A571 MARATHON 80 B5 FLANGE MOUNTING KIT

A571 MARATHON 80 B5 FLANGE MOUNTING KIT

MSRP: $75.00

Regular Price

$

48

00

Image for A563 MARATHON 80 FRAME B14 FLANGE MOUNTING KIT
