Product Overview

Littelfuse SymCom 201-200-SP-T-9 MotorSaver is an octal-base, plug-in voltage monitor designed to protect single-phase motors regardless of size. It is used on 190-240VAC, 50 or 60Hz motors to prevent damage caused by low voltage. The 201-200-SP-T-9 is a pin-for-pin replacement for a Time Mark(r) #260 Series voltage monitor and includes High Voltage protection.

Part Number:

MS201200SPT9

Manufacturer:

Littelfuse SymCom

Manufacturer Part Number:

201-200-SP-T-9

Technical Details

Specifications

Product Family	MotorSaver
Model Type	201A
Input Power	190-240VAC
Input Phase	1
Input Hz	60/50
Voltage Monitoring	Adjustable, High Voltage

Documentation

Product Packet

Installation Instructions

Additional Information

Littelfuse SymCom 201-200-SP-T-9 MotorSaver Protection Relay is a unique single-phase microcontroller-based voltage and phase-sensing circuit that constantly monitors the voltage to detect harmful power line conditions. When a harmful condition is detected, the MotorSaver's output relay is deactivated after a specified trip delay. The output relay reactivates after power line conditions return to acceptable level specified amount of time (restart delay). The trip delay prevents nuisance tripping due to rapidly fluctuating power line conditions.

The Model 201-200-SP-T-9 is used on 190-240VAC, 60/50Hz single-phase motors and is a pin-for-pin replacement for a Time Mark #260 Series voltage monitor. High voltage protection is included in the 201-200-SP-T-9 model.

Features:
• Diagnostic LED for troubleshooting and to determine relay status
• Trip delay prevents nuisance tripping due to rapidly fluctuating power line conditions (fixed, 4 seconds)
