250HP LINCOLN 1750RPM 447TC TEFC 460V 3PH MOTOR LM13583

250HP LINCOLN 1750RPM 447TC TEFC 460V 3PH MOTOR LM13583


Part Number:

LM13583

Model/Spec Number:

SF4P250TC64Y

Manufacturer:

Lincoln
LM13583 LINCOLN 250HP Three Phase TEFC Motor is designed for use where exposure is limited to splashes of water, dust and/or where mild corrosives exist.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

1,833 lbs

Dimensions:

24 x 36 x 24 inches

HS Code:

8501.51.6000

Technical Details

Brand:

Lincoln

Application:

General Purpose

Output HP:

250

Output KW:

187.0

Output RPM:

1750

Frame Size NEMA:

447TC

Mount NEMA:

C Face With Base

Enclosure NEMA:

TEFC

Enclosure IEC:

IP43

Voltage:

460

Motor Drawing

Connection Diagram

Volts 460 Volts   Volts 415
F.L. Amps 283 F.L. Amps   F.L. Amps 315
S. F Amps 325 S. F Amps   S. F Amps
RPM 1800 Hertz 60/50
HP 250 Duty CONTINUOUS TYPE TFR
KW 187
Frame 447TC Serv. Factor 1.15 Phase 3
Max Amb 40 Design BC Code G
Insul Class F Protection NOT Therm.Prot.
Eff 100% 95 Eff 75%   PF 87
UL V-INS, CONST UL REC CSA Yes Bearing OPE 315
CC Number CC004A CE Yes Bearing PE 318
Load Type   Inverter Type NONE Speed Range NONE
Motor Wt. 1820 LB Enclosure TEFC Lubrication STANDARD
Nameplate 3B451-A-X-ABCD-MZ-A-X Mounting RIGID Rotation REV
