1/4HP LEESON 1800RPM 63D IP54 24VDC IEC PERMANENT MAGNET MOTOR M1130207.00

Picture is for reference only.

Part Number:

M1130207.00

Manufacturer:

Leeson Obsolete

Manufacturer Part Number:

CIM34D18FD6

M1130207.00 LEESON 1/4HP 24VDC Metric IEC Frame IP54 Motor is built to IEC 34-1 electrical and mechanical standards.

Informational Item

This is item is for informational purposes only and cannot be purchased. Please contact customer service for more details.

Shipping Details

Weight:

16 lbs

Dimensions:

10 x 15 x 10 inches

HS Code:

8501.31.4000

UPC:

691720091579

Technical Details

Specifications

Application:	General Purpose
Output HP:	1/4
Output KW:	0.18
Output RPM:	1800
Frame IEC:	63D
Mount IEC:	B5
Input Voltage DC:	24
Full Load Amps:	10.0
Winding:	Permanent Magnet
Enclosure NEMA:	TEFC

Documentation

Product Information Packet

Additional Information

LEESON DC METRIC IEC Frame IP54 Motors are built to IEC 34-1 electrical and mechanical standards. The IEC 63 and smaller frames are stocked with an integral B5 flange or B14 face less base. An optional B3 rigid base kit is available. A unique modular approach for IEC 71 frame and larger allows the motor to be field modified to B3 rigid base mounted construction, B5 flange mounted or B14 face mounted construction using conversion kits. Please note the one or more of the mounting kits must be used with IEC motors of these frame sizes.

Electrical & Mechanical Features: A terminal board is provided for connections. All fasteners are metric. Electrical and mechanical features are the same as listed for the NEMA frame motors. Tachometer mounting kits are available for 71 and 80 frames only.
