1/4HP LEESON 62RPM TENV 90VDC WASHDOWN RIGHT ANGLE GEARMOTOR M1125277.00

LEESON IP55 Epoxy Washguard DC Right Angle Gearmotor

Features:

• 5/8" Keyed output shaft with flat
• 303 stainless steel gearbox output shaft
• Frame, endshields, armature and interior components protected by enamel and polyester compounds for resistance to moisture, acids, alkalies and oil
• Cast conduit box with threaded conduit holes and nitrile gaskets keep water out
• Conduit box cover is made from 304 stainless steel
• For any condensation that may accumulate inside the motor, a one-way stainless steel vapor vent is provided
• All hardware is stainless steel
• Painted with white epoxy for superior corrosion resistance and protection
• Machined fits between the endbells and motor frame are sealed with gaskets
• Thru-bolt heads and nuts sealed with fiber washers
• O-rings under each threaded brush cover
• Worm-type right-angle gearing features hardened, steel worm with bronze worm wheel for long life and quiet operation
• Precision machined aluminum gear housing
• Lubrication is permanent with an oil bath
• Gearbox has all ball bearings
• Output shaft is field interchangeable from left hand to right hand style by reassembly

Application Notes

• These right-angle gearmotors have a lubrication breather positioned for horizontal mounting. For other mountings, the breather plug must be reoriented by using a 90 deg 1/8” NPT taper pipe elbow. Regal does not offer this elbow.
• It is not recommended to place the gearmotor with the gearbox shaft up to prevent leakage of lubricant into the motor should the motor shaft seal fail.
