30HP LEESON 1775RPM 286T TEFC 3PH MOTOR G150015.60
30HP LEESON 1775RPM 286T TEFC 3PH MOTOR G150015.60
Picture is for reference only.
Part Number:
G150015.60Manufacturer:
Leeson ObsoleteManufacturer Part Number:
C286T17FB7CClick below to view suggested functional replacement.
Shipping Details
Weight:
440 lbsDimensions:
24 x 32 x 24 inchesHS Code:
8501.52.0000Technical Details
Specifications
Brand: | Leeson |
Application: | General Purpose |
Output HP: | 30//25 |
Output RPM: | 1775//1450 |
Frame Size NEMA: | 286T |
Mount NEMA: | With Base |
Enclosure NEMA: | TEFC |
Enclosure IEC: | IP44 |
Voltage: | 230/460//190/380 |
Frequency (Hz): | 60//50 |
Documentation
Additional Information
TEFC Models: For use where exposure is limited to splashes of water, dust and/or where mild corrosives exist. Ideally, suited for use on pumps, compressors, blowers, fans, conveyors, machine tools and other direct or belt-driven applications. Not for outdoor use without proper shielding or for use with harsh chemicals.
| Volts | 208-230 | Volts | 460 | Volts | 190/380 |
| F.L. Amps | 73.5-69.8 | F.L. Amps | 34.9 | F.L. Amps | 70.0/35.0 |
| S. F Amps | 88.0 | S. F Amps | 44.0 | S. F Amps | 80.0/40.0 |
| RPM | 1800 | Hertz | 60/50 | ||
| HP | 30 | Duty | CONTINUOUS | TYPE | TF |
| KW | 22.4 | Model Number | C286T17FB7C | ||
| Frame | 286T | Serv. Factor | 1.25 | Phase | 3 |
| Max Amb | 40 | Design | B | Code | G |
| Insul Class | F | Protection | NOT | Therm.Prot. | |
| Eff 100% | 92.4 | Eff 75% | PF | 87 | |
| UL | Yes | CSA | Yes | Bearing OPE | 6309 |
| CC Number | 005A | CE | Yes | Bearing PE | 6311 |
| Load Type | Inverter Type | NONE | Speed Range | NONE | |
| Motor Wt. | 438 LB | Enclosure | TEFC | Lubrication | STANDARD |
| Nameplate | 080307 | Mounting | RIGID | Rotation | REV |
