3HP LEESON 3490RPM 145TC TEFC 3PH MOTOR G120993.00

3HP LEESON 3490RPM 145TC TEFC 3PH MOTOR G120993.00

Picture is for reference only.

Part Number:

G120993.00

Model/Spec Number:

C145T34FC39

Manufacturer:

Leeson Obsolete
G120993.00 LEESON 3HP Three Phase TEFC Motor is designed for use where exposure is limited to splashes of water, dust and/or where mild corrosives exist.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

60 lbs

Dimensions:

13 x 22 x 13 inches

HS Code:

8501.52.8040

Technical Details

Brand:

Leeson

Application:

General Purpose

Output HP:

3

Output KW:

2.2

Output RPM:

3490

Frame Size NEMA:

143-5TC

Mount NEMA:

C Face No Base

Enclosure NEMA:

TEFC

Enclosure IEC:

IP43

Voltage:

230/460

Motor Drawing

Connection Diagram

Volts208-230Volts460Volts
F.L. Amps8.4-7.6F.L. Amps3.8F.L. Amps
S. F Amps9.6-8.6S. F Amps4.3S. F Amps
RPM3600Hertz60
HP3DutyCONTINUOUSTYPETF
KW2.24Model NumberC145T34FC39 A
Frame145TCServ. Factor1.15Phase3
Max Amb40DesignBCodeL
Insul ClassFProtectionNOTTherm.Prot.
Eff 100%85.5Eff 75% PF86
ULYesCSAYesBearing OPE6203
CC NumberNONECENoBearing PE6205
Load Type Inverter Type Speed RangeNONE
Motor Wt.44 LBEnclosureTEFCLubricationPOLYREX EM
Nameplate993500MountingC FACERotationREV
