20HP LEESON 1760RPM 256T TEAO 3PH MOTOR 824533

This LEESON Motor Can Only Ship Ground Freight.
For expedited needs please contact our sales team.

Applications: Cooling towers, Fan and Blowers, and other severe duty environments where long life and high efficiency are desired.

Premium Features:

• Made in the USA
• Two year warranty
• Epoxy painted
• Designed for shaft up mounting
• Shaft grounding ring (SGRs) installed
• 10 : 1 constant and variable torque rated
• Complete cast iron construction for rigidity and reduced vibration
• Inpro Shaft seal protected
• Class F insulation
• F-1 / F-2 Capable
• Inverter rated IRIS™ insulation system
• Extra nameplate with CE for external mounting
• Brass T-drain installed - both ends at 6:00
• Re-greaseable bearings
• Severe duty treatment of internal parts
• 1.15 S.F. under sine wave power

Volts	230	Volts	460	Volts
F.L. Amps	50	F.L. Amps	25	F.L. Amps
S. F Amps	57	S. F Amps	28.5	S. F Amps
RPM	1800	Hertz	60
HP	20	Duty	CONTINUOUS AOM	TYPE	TNS
KW	14.9
Frame	256TV	Serv. Factor	1.15	Phase	3
Max Amb	40	Design	B	Code	F
Insul Class	F	Protection	NOT	Therm.Prot.
Eff 100%	91	Eff 75%		PF	82
UL	Y-(LEESON UL REC)	CSA	Yes	Bearing OPE	6210
CC Number	EXEMPT	CE	Yes	Bearing PE	6309
Load Type		Inverter Type		Speed Range	NONE
Motor Wt.	400 LB	Enclosure	TEAO	Lubrication	STANDARD
Nameplate	92720-BM-ACDLM-HJK-A-X-D	Mounting	RIGID	Rotation	REV
Assembly		Shaft Dia.		Ext. Diag.	A-EE7308-LE
