20HP LEESON 1773RPM 256JM DP 3PH PUMP MOTOR 199966.00

20HP LEESON 1773RPM 256JM DP 3PH PUMP MOTOR 199966.00


Part Number:

199966.00

Model/Spec Number:

C256T17DK8

Manufacturer:

Leeson Obsolete
199966.00 LEESON 20HP Three Phase Premium JM Pump Motor is designed for continuous duty service on close-coupled pumps using NEMA JM mounting provisions.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

69 lbs

Dimensions:

14 x 22 x 14 inches

HS Code:

8501.52.4000

Technical Details

Brand:

Leeson

Application:

Closed Coupled

Output HP:

20

Output KW:

14.9

Output RPM:

1773

Frame Size NEMA:

256JM

Mount NEMA:

C Face With Base

Enclosure NEMA:

DP

Enclosure IEC:

IP22

Voltage:

230/460

Connection Diagram

Motor Drawing
