10HP LEESON 3520RPM 215TC TEFC 3PH STAINLESS WASHDOWN SST MOTOR 194006.00
10HP LEESON 3520RPM 215TC TEFC 3PH STAINLESS WASHDOWN SST MOTOR 194006.00
Part Number:
194006.00Model/Spec Number:
C215T34FK1Manufacturer:
Marathon LLCTechnical Details
Specifications
Brand: | Leeson |
Application: | Washdown Stainless |
Output HP: | 10//7.5 |
Output KW: | 7.5//5.6 |
Output RPM: | 3520//2940 |
Frame Size NEMA: | 215TC |
Mount NEMA: | C Face With Base |
Enclosure NEMA: | TEFC |
Enclosure IEC: | IP55 |
Voltage: | 230/460//190/380 |
Documentation
Additional Information
LEESON Three Phase Washguard Stainless Duck Motor is designed for long-life in demanding washdown applications. Built with all stainless steel external components and well sealed against moisture and condensation, these all-stainless motors are able to withstand severe washdown environments. When a paint-free motor is needed for ultra-clean operations in the food processing, bottling and pharmaceutical industries, count on LEESON Stainless Duck motors to meet the need—at a price that defines value.
Features:
- NEMA Premium efficiency with a three year warranty
- Inverter Rated - Variable 10:1
- 300 Series stainless steel exterior components
- 1-3/8" Keyed output shaft
- C-face mounting provisions with heavy duty 12G stamped base
- Buna-N gaskets and Viton shaft seals
- TEFC models: Seals and gaskets on both ends of shaft extension
- Anti-corrosion coating applied to rotor and stator
- Moisture resistant sealant between frame and endshields
- Laser etched full-fact nameplate
- Double sealed bearings
- Split conduit box design with flanged cover and rubber gasket
- Condensate drains for all mounting orientations in each endshield
- IRIS Inverter duty insulation system (Class F) - 1HP and higher
