141357.00 LEESON 15HP WASHDOWN MOTOR C215T34WC8

Electric Motors

Three Phase Electric Motors

Leeson Motors Three Phase

LEESON Three Phase Epoxy Washguard Motors

15HP LEESON 3495RPM 215TC TEFC 3PH EPOXY WASHDOWN MOTOR 141357.00

Picture is for reference only.

Part Number:

141357.00

Model/Spec Number:

C215T34WC8

Manufacturer:

Marathon LLC

141357.00 LEESON 15HP Three Phase White Duck Washguard Epoxy Motor is designed for enhanced performance in wet, humid areas. Designed to meet the demanding washdown conditions that you may find in food processing plants, chemical processing, pharmaceutical plants, and the beverage and brewing industries.

MSRP: $4,290.00

Regular Price

USD

2,960

QTY

Shipping Details

Weight:

156 lbs

Dimensions:

23 x 29 x 20 inches

HS Code:

8501.52.4000

UPC:

691720991442

Technical Details

Specifications

Brand:	Leeson
Application:	Washdown Epoxy
Output HP:	15
Output KW:	11.2
Output RPM:	3495
Frame Size NEMA:	215TC
Mount NEMA:	C Face No Base
Enclosure NEMA:	TEFC
Enclosure IEC:	IP55
Voltage:	230/460//190/380

Documentation

Product Information Packet

Additional Information

LEESON Three Phase White Duck Washguard Epoxy Motor is designed for enhanced performance in wet, humid areas. Designed to meet the demanding washdown conditions that you may find in food processing plants, chemical processing, pharmaceutical plants, and the beverage and brewing industries.

NEMA Premium efficiency rating with a three year warranty
The original moisture-shedding "duck" motor
Durable rolled steel frame
USDA-approved, high-gloss, white epoxy finish
1-3/8" Keyed output shaft
303 stainless-steel shaft and moisture-resistant shaft system
Frame, base, endshields, rotor, and interior components are protected by enamel and polyester compounds
High temperature, moisture resistant IRIS® insulation system
Cast, oversized conduit box with tough, high-temperature nitrile gaskets and stainless-steel cover and hardware
Excellent for applications requiring a motor that is "tropicalized"
Double-sealed, oversized bearings
Stainless-steel or white polypropylene fan guard on all Washguard frames.
Stainless-steel, “full-fact” nameplate
Four condensate drains in each endshield
