122191.00 LEESON 3HP 3PH WASHDOWN PUMP MOTOR C145T34WK39

3HP LEESON 3490RPM 145JM TEFC 3PH EPOXY WASHDOWN PUMP MOTOR 122191.00

Part Number:

122191.00

Model/Spec Number:

C145T34WK39

Manufacturer:

Regal Rexnord Commercial

122191.00 LEESON 3HP Three Phase White Duck Epoxy Washguard JM Pump Motor is designed for demanding pump applications requiring a JM shaft in wet, humid areas. Designed to meet the industrial washdown conditions that you may find in food processing plants, chemical processing, pharmaceutical plants, and the beverage and brewing industries.

MSRP: $2,996.00

Regular Price

USD

1,126

QTY

Shipping Details

Weight:

54 lbs

Dimensions:

13 x 22 x 13 inches

HS Code:

8501.52.4000

UPC:

691720052075

Technical Details

Specifications

Brand:	Leeson
Application:	Closed Couple
Output HP:	3
Output KW:	2.2
Output RPM:	3490
Frame Size NEMA:	145JM
Mount NEMA:	C Face With Base
Enclosure NEMA:	TEFC
Enclosure IEC:	IP55
Voltage:	208-230/460

Documentation

Product Information Packet

Additional Information

LEESON Three Phase White Duck Epoxy Washguard JM Pump Motor is designed for demanding pump applications requiring a JM shaft in wet, humid areas. Designed to meet the industrial washdown conditions that you may find in food processing plants, chemical processing, pharmaceutical plants, and the beverage and brewing industries.

NEMA Premium efficiency rating with a three year warranty
The original moisture-shedding "duck" motor
Durable rolled steel frame with rigid base
USDA-approved, high-gloss, white epoxy finish
303 stainless-steel shaft and moisture-resistant shaft system
Frame, base, endshields, rotor, and interior components are protected by enamel and polyester compounds
High temperature, moisture resistant IRIS® insulation system
Cast, oversized conduit box with tough, high-temperature nitrile gaskets and stainless-steel cover and hardware
Excellent for applications requiring a motor that is "tropicalized"
Double-sealed, oversized bearings
Stainless-steel or white polypropylene fan guard on all Washguard frames.
Stainless-steel, “full-fact” nameplate
Four condensate drains in each endshield
