1HP LEESON 1760RPM 56C TEFC 3PH WATTSAVER BRAKE MOTOR 119563.00
1HP LEESON 1760RPM 56C TEFC 3PH WATTSAVER BRAKE MOTOR 119563.00
Product Overview
119563.00 LEESON 1HP Three Phase Totally Enclosed Brake motor is designed for use with conveyors, packaging equipment, machine tools, hoists, elevators and door operators.Part Number:
119563.00Model/Spec Number:
C6T17FK105AManufacturer:
Regal Rexnord CommercialManufacturer Part Number:
119563.00Technical Details
Specifications
| Brand | Leeson |
| Application | Brakemotor |
| Output HP | 1 |
| Output KW | 0.75 |
| Output RPM | 1760 |
| Frame Size NEMA | 56C |
Documentation
Additional Information
LEESON Fail-safe positive, stop and hold brake-motors. Brakes are spring set. Load stopped automatically when power is turned off. LEESON brake-motors feature a power off manual release for convenience, and for use in case of a power failure. The manual release resets automatically. The standard brake is manufactured by Stearns. The brake coil leads are brought into the conduit box of the motor for easy connection and may be connected to operate when power to the motor is shut off, or to be actuated independent of power to the motor.
FEATURES:
- 5/8" Keyed output shaft
- High-quality ball bearings
- Easy-to-read nameplate
- UL Recognized Component Listing and CSA approval
Related Items
Automation Products
Related Products
MSRP: $2,984.00
Regular Price
USD
$
1,240
00
