1HP LEESON 1725RPM 56C TEFC 3PH UNIT HANDLING MOTOR 117713.00
1HP LEESON 1725RPM 56C TEFC 3PH UNIT HANDLING MOTOR 117713.00
Part Number:
117713.00Model/Spec Number:
C6T17FC228Manufacturer:
Leeson ObsoleteClick below to view suggested functional replacement.
Shipping Details
Weight:
26 lbsDimensions:
12 x 20 x 12 inchesHS Code:
8501.52.4000Technical Details
Specifications
Brand: | Leeson |
Application: | Unit Handling |
Output HP: | 1 |
Output KW: | 0.75 |
Output RPM: | 1725 |
Frame Size NEMA: | 56C |
Mount NEMA: | C Face No Base |
Enclosure NEMA: | TEFC |
Enclosure IEC: | IP43 |
Voltage: | 208-230/460 |
Documentation
Additional Information
| Volts | 208-230 | Volts | 460 | Volts | |
| F.L. Amps | 3.6-3.8 | F.L. Amps | 1.9 | F.L. Amps | |
| S. F Amps | 4.2 | S. F Amps | 2.1 | S. F Amps | |
| RPM | 1800 | Hertz | 60 | ||
| HP | 1 | Duty | CONTINUOUS | TYPE | TF |
| KW | .75 | Model # | C6T17FC228 | ||
| Frame | 56C | Serv. Factor | 1.15 | Phase | 3 |
| Max Amb | 40 | Design | B | Code | M |
| Insul Class | F | Protection | NOT | Therm.Prot. | |
| Eff 100% | 77 | Eff 75% | PF | 64 | |
| UL | Y-(LEESON UL REC) | CSA | Yes | Bearing OPE | 6203 |
| CC Number | EXEMPT | CE | No | Bearing PE | 6203 |
| Load Type | Inverter Type | Speed Range | NONE | ||
| Motor Wt. | 26 LB | Enclosure | TEFC | Lubrication | POLYREX EM |
| Nameplate | 993500 | Mounting | ROUND | Rotation | REV |
| Assembly | Shaft Dia. | 5/8 IN | Ext. Diag. | 005010.01 |
