1/3HP LEESON 3450RPM 56C TEFC 1PH EPOXY WASHDOWN MOTOR 113580.00

1/3HP LEESON 3450RPM 56C TEFC 1PH EPOXY WASHDOWN MOTOR 113580.00

WASHGUARD 56 FRAME TEFC CFACE WITH BASE.jpg
Picture is for reference only.

Part Number:

113580.00

Model/Spec Number:

C6C34WK2

Manufacturer:

Leeson Obsolete
113580.00 LEESON 1/3HP Single Phase Washguard Epoxy Motor designed for enhanced performance in wet, humid areas that you may find in food processing plants, chemical processing, pharmaceutical plants and the beverage and brewing industries.

Item Discontinued

Click below to request an agent review potential options.

Weight:

32 lbs

Dimensions:

13 x 17 x 13 inches

HS Code:

8501.40.4040

UPC:

691720012055

Technical Details

Application:

Washdown Epoxy

Output HP:

1/3

Output KW:

0.25

Output RPM:

3450

Frame NEMA:

56C

Mount NEMA:

C-Face With Base

Enclosure NEMA:

TEFC

Enclosure IEC:

IP55

Voltage:

115/208-230

Frequency (Hz):

60

Product Information Packet
