1HP LEESON 1750RPM 56C TEFC 12VDC EPOXY WASHGUARD MOTOR 109295.00

1HP LEESON 1750RPM 56C TEFC 12VDC EPOXY WASHGUARD MOTOR 109295.00

Picture is for reference only.

Part Number:

109295.00

Model/Spec Number:

C4D18WK11
109295.00 LEESON 1HP WASHGUARD is a low voltage permanent magnet DC motor suitable for installations having battery or solar powered operation. High starting torque and reverse rotation.

Ordering Notes

Discontinued. This motor is limited quantities and subject to prior sale. Non-returnable.
MSRP: $1,310.00

Regular Price

USD

$

610

00

QTY
Login to View Discounts

Free No Rush Shipping

Weight:

45 lbs

Dimensions:

11 x 20 x 11 inches

HS Code:

8501.32.2000

Technical Details

Application:

Epoxy Washdown

Output HP:

1

Output KW:

0.75

Output RPM:

1750

Frame NEMA:

56C

Mount NEMA:

C-Face With Base

Input Voltage DC:

12

Full Load Amps:

80.0

Winding:

Permanent Magnet

Enclosure NEMA:

TEFC

Motor Drawing

RPM 1800 HP 1 Serv. Factor 1.0 KW Form Factor 1.00 AMPs 80 KW2 Form Factor 2 FLA2 Volts 12 Frame 56C Max Amb 40 Duty CONT TYPE DF Insul Class H Enclosure TEFC Bearing OPE 6203 Protection NOT Protector Bearing PE 6203 EFF 77.9% Torque 35 LB-IN UL Yes CSA Yes CE No Motor Wt. Nameplate 109295.00 Lubrication POLYREX EM Carton Label Individual Assembly Mounting C-Face Rigid Rotation RECONN Winding D55477 Ext. Diag. Ext. Diag2 GROUP 1 A Shaft Dia. 5/8 IN Packaging STD Sub Group A Paint EPOXY WT 01 Outline 612-0198-000 Cust Part No None
Image for 120 AMP LEESON 12/24VDC CHASSIS SPEED CONTROL 174298.00

120 AMP LEESON 12/24VDC CHASSIS SPEED CONTROL 174298.00

MSRP: $1,850.00

Regular Price

$

1,187

70

Image for GROVE GR-WBMQ818-10-R-56 WASHGUARD RIGHT ANGLE GEAR REDUCER GR8183015.00

GROVE GR-WBMQ818-10-R-56 WASHGUARD RIGHT ANGLE GEAR REDUCER GR8183015.00

MSRP: $2,001.12

Regular Price

$

1,033

56

Image for GROVE GR-WBMQ818-10-L-56 WASHGUARD RIGHT ANGLE GEAR REDUCER GR8183003.00

GROVE GR-WBMQ818-10-L-56 WASHGUARD RIGHT ANGLE GEAR REDUCER GR8183003.00

MSRP: $2,001.12

Regular Price

$

1,033

56

Image for GROVE GR-WBMQ818-10-D-56 WASHGUARD RIGHT ANGLE GEAR REDUCER GR8183027.00

GROVE GR-WBMQ818-10-D-56 WASHGUARD RIGHT ANGLE GEAR REDUCER GR8183027.00

MSRP: $2,064.16

Regular Price

$

1,099

63

Image for 1HP LEESON 1800RPM 56C TEFC 12VDC EPOXY WASHDOWN MOTOR 109302.00
