3/4HP LEESON 3450RPM S56C DP 3PH GENERAL PURPOSE MOTOR 100378.00

3/4HP LEESON 3450RPM S56C DP 3PH GENERAL PURPOSE MOTOR 100378.00

Picture is for reference only.

Part Number:

100378.00

Model/Spec Number:

C4T34DC3

Manufacturer:

Leeson Obsolete
100378.00 LEESON 3/4HP DP Electric Motor is designed for use where water and dust exposure is moderate.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

23 lbs

Dimensions:

12 x 20 x 12 inches

HS Code:

8501.51.4000

UPC:

691720004852

Technical Details

Brand:

Leeson

Application:

General Purpose

Output HP:

3/4

Output KW:

0.55

Output RPM:

3450

Frame Size NEMA:

S56C

Mount NEMA:

C Face No Base

Enclosure NEMA:

DP

Enclosure IEC:

IP22

Voltage:

230/460

Product Information Packet
