GRL-HMQ821-50-H1-56-20 GROVE 50:1 H1 RIGHT ANGLE GEAR REDUCER GRL8210545.20
GRL-HMQ821-50-H1-56-20 GROVE 50:1 H1 RIGHT ANGLE GEAR REDUCER GRL8210545.20
Picture is for reference only.
Part Number:
GRL8210545.20Manufacturer:
Grove GearManufacturer Part Number:
GRL8210545.20 GROVE Gearing products are Non-Returnable. Once the order is placed it cannot be canceled. Standard lead times are 5-10 business days.
MSRP: $2,570.06
Regular Price
USD
$
1,325
32
Shipping Details
Free No Rush Shipping
Weight:
30 lbsDimensions:
14 x 14 x 14 inchesHS Code:
8483.00.0000UPC:
690310049662Technical Details
Specifications
Max Input HP @1750: | 0.77 |
Output RPM @1750: | 35 |
Reduction Ratio: | 50:1 |
Torque (lb-in)@1750rpm: | 970 |
Overhung Load (lbs.): | 1000 |
Shaft Center Distance: | 2.06 |
Shaft Center Height: | 2.28 |
Mount Footprint: | 2.88” x 5.00” |
NEMA Input Mounting: | 56C |
Mount Style: | HMQ |
Documentation
Additional Information
Grove Cast Iron Right Angle Worm Gear Reducer is designed for a wide variety of applications requiring slow speed and high torque, ideal for conveyors, material handling, textile machines, packaging machinery, etc. FEATURES: Heavy duty cast iron housing Factory-filled premium Mobil Glygoyle 460 polyalkalene lubricant Precision machined mounting surfaces O-rings on input and output covers Viton double lip seals provide extended life NEMA C input flange, Push-off holes Bronze worm gear chill cast from high quality bronze Tapered roller bearings Premium Grade 5 assembly bolts throughout Mounting dimensions are interchangeable with most industry standard reducer
