Product Overview

708200L GROVE TXMQ-2.000-48CZ-56C Die Cast Aluminum Ratio Multiplier can reduce or increase input speed when combined with right angle units for high ratios.

Part Number:

708200L

Model/Spec Number:

TXMQ-2.000-48CZ-56C

Manufacturer:

Grove Gear

Manufacturer Part Number:

708200L

Technical Details

Specifications

Design	Ratio Multiplier
Output RPM@1750	875
Output Torque (lb-in)	424
Max Input HP @1750	5
Ratio	2.000
NEMA Input Config	48C / .500"

Documentation

Ratio Multiplier Brochure

Ratio Multiplier Dimensions

Installation & Operation Manual

Grove Warranty

Additional Information

GROVE Die Cast Aluminum Ratio Multipliers can reduce or increase input speed when combined with right angle units for high ratios.

FEATURES:

Helical gearing to optimize system efficiency.
Viton® double lip seals provide extended life through increased resistance to high temperature, abrasion and chemicals.
Washdown Friendly Exterior
Die Cast Aluminum construction
Factory-filled with premium Mobil Glygoyle 460 polyalkalene glycol lubricant – USDA Class H1 approved.
Internal compression chamber eliminates breather vent
Standard Grove Gear blue paint
Universal mounting positions
High Torque Ratings
