1/8HP BISON 24RPM TENV 230VAC 3ph Stainless Parallel SaniMotor Gearmotor 017-261-0072
1/8HP BISON 24RPM TENV 230VAC 3ph Stainless Parallel SaniMotor Gearmotor 017-261-0072
Part Number:
0172610072Manufacturer:
Bison GearManufacturer Part Number:
017-261-0072Technical Details
Specifications
Design: | Parallel Shaft |
Input HP: | 1/8 |
Output KW: | 0.093 |
Output RPM@60hz: | 24 |
Gear Ratio: | 71.5:1 |
Torque Lb-in.@60hz: | 256 |
Overhung Load (lb.): | 300 |
Voltage AC: | 230 |
Full Load Amp@60hz: | 0.5 |
Frequency (Hz): | 6-60 |
Documentation
Additional Information
BISON Inverter Duty Stainless Steel SantiMotor 3ph Parallel Gearmotor is designed to meet the IP69K extreme washdown rating for equipment exposed to constantly wet environments, and the use of harsh cleaning agents.
FEATURES:
- Requires power cord (see related products)
- Gearing: Precision machined on automated CNC mills
- Geartrain: Engineered to handle up to 200% shock-loading
- Housing: 304 stainless steel
- Lubrication: High performance grease for food processing
- Shafts: 5/8" Keyed 304 Stainless Output Shaft
- Mounting: All position
- Motor Type: 230VAC, 3 phase Inverter Duty
- 6-60 Hz Constant Torque
- 60-90 Hz Constant Horsepower
- Motor Bearings: Sealed ball bearings
- Insulation: Class F (155ºC)
- Enclosure: TENV
- Global safety recognition: UL
- Ambient temperature: 0º to 40ºC
- Continuous duty
- Maximum cable length not to exceed 50ft
