017-175-0013 BISON 1/12HP 3PH PARALLEL GEARMOTOR

Gear Motors

Gearmotors Three Phase

BISON GEAR Three Phase Gearmotors

BISON GEAR 3PH Parallel Gearmotors

BISON 175 SERIES AC 3PH PARALLEL GEARMOTORS

1/12HP BISON 122RPM TEFC 230/460VAC 3PH 175 SERIES PARALLEL GEARMOTOR 017-175-0013

Picture is for reference only.

Part Number:

0171750013

Manufacturer:

Bison Gear

Manufacturer Part Number:

017-175-0013

017-175-0013 BISON 1/12HP 122RPM 230/460VAC 3PH 175 SERIES Parallel Shaft Gearmotor for general purpose applications including conveyors, material handling equipment and packaging machinery.

Ordering Notes

This part is non-returnable. Use the Cut-Sheet provided to confirm product specs.

Informational Item

This is item is for informational purposes only and cannot be purchased. Please contact customer service for more details.

Shipping Details

Free No Rush Shipping

Weight:

11 lbs

Dimensions:

8 x 17 x 8 inches

HS Code:

8501.51.4020

Technical Details

Specifications

Design:	Parallel Shaft
Input HP:	1/12
Output KW:	0.062
Output RPM@60hz:	122
Gear Ratio:	12.9:1
Torque Lb-in.@60hz:	38
Overhung Load (lb.):	220
Voltage AC:	230/460
Full Load Amp@60hz:	0.60/0.35
Frequency (Hz):	60//50

Documentation

Product Information Packet

Additional Information

APPLICATIONS: Conveyors, medical and laboratory equipment, printing presses, commercial broiling ovens, machine tools and many other applications.

FEATURES:

Gearing: 1st-stage helical steel, balance heat treated steel or powdered metal
Geartrain: Engineered to handle up to 200% shockloading
Housing: Precision machined die cast aluminum
Lubrication: Lifetime oil bath, sealed and gasketed
Gearhead Bearings: Needle output
Shafts: Precision ground, Hardened steel
Mounting: Face or optional footplate (any angle)
Motor Type: 230/460VAC, 3 phase
Rotation: Reversible
Motor Bearings: Shielded ball bearing
Insulation: Class F
Enclosure: TEFC
Rating: Continuous duty
