7/50HP BISON 12RPM ODP 115VAC VWDIR20 SERIES PARALLEL GEARMOTOR 014Q307-0144
7/50HP BISON 12RPM ODP 115VAC VWDIR20 SERIES PARALLEL GEARMOTOR 014Q307-0144
Part Number:
014Q3070144Manufacturer:
Bison GearManufacturer Part Number:
014Q307-0144This part is non-returnable. Use the Cut-Sheet provided to confirm product specs.
Regular Price
USD
$
883
77
Shipping Details
Free No Rush Shipping
Weight:
15 lbsDimensions:
8 x 16 x 8 inchesHS Code:
8501.40.2020Technical Details
Specifications
Design: | Parallel Shaft |
Input HP: | 7/50 |
Output KW: | 0.104 |
Output RPM: | 12 |
Gear Ratio: | 144.2:1 |
Torque Lb-In: | 600 |
Overhung Load (lb.): | 300 |
Voltage: | 115 |
Full Load Amperage: | 3.3 |
Frequency (Hz): | 60 |
Documentation
Additional Information
BISON VWDIR20 SERIES 115VAC Split Phase Parallel Shaft Gearmotor. General purpose including conveyors, material handling equipment and packaging machinery. Direct replacement for Dayton 1LPP6
FEATURES:
- 3/4" Output shaft with woodruff key
- Gearing: Phenolic high speed and steel
- Housing: Precision machined die cast aluminum
- Lubrication: Grease
- Bearings: Porous bronze sleeve
- Shafts: Hardened steel
- Mounting: Baseplate (any position)
- Motor Type: Split Phase
- Rotation: Reversible
- Insulation: Class B minimum
- Finish: Unpainted
- Enclosure: ODP
