XM21142T BALDOR 10HP EXPLOSION PROOF MOTOR 37-0000-0046

10HP BALDOR 1770RPM 215T XPFC 3PH EXPLOSION PROOF MOTOR XM21142T

Part Number:

XM21142T

Model/Spec Number:

37-0000-0046

Manufacturer:

ABB/Baldor

XM21142T BALDOR 10HP Explosion Proof Motor is ideal for hazardous location applications driving pumps, compressors, blowers, fans, and many other loads that require hazardous location protection.

Technical Details

Specifications

Brand:	Baldor
Application:	Explosion Proof
Output HP:	10//7.5
Output KW:	7.5
Output RPM:	1770//1475
Frame Size NEMA:	215T
Mount NEMA:	With Base
Enclosure NEMA:	XPFC
Enclosure IEC:	IP54
Voltage:	230/460//190/380

Documentation

XM21142T-InfoPacket (1).pdf

Explosion-Proof-Definitions.pdf

Additional Information

Division 1 Explosion Proof motors are designed and built to contain an explosion inside and not propagate it into the surrounding atmosphere.

APPLICATIONS: Pumps, fans and conveyors with fixed and variable speed operation

FEATURES:

Auto thermal overload (<1 Hp), normally closed thermostats (≥1 Hp)
Threaded lead inlet
Low noise vibration dampening bases

CAUTION: Explosion-proof motors have a tight fit between mating parts to ensure the integrity of the explosion-proof enclosure. This can lead to an accumulation of moisture inside the motors due to condensation. If internal condensation buildup is a concern for your XP motor application, select a motor that includes UL listed breather drain. Care should be used when selecting an explosion-proof motor, especially when installed outdoors and on intermittent duty. Consider Drill Rig Duty Explosion-proof motors for outdoor applications.
