1.5HP BALDOR 1750RPM 90D TEFC 180VDC B5 PERMANENT MAGNET MOTOR VP3575D
1.5HP BALDOR 1750RPM 90D TEFC 180VDC B5 PERMANENT MAGNET MOTOR VP3575D
Product Overview
VP3575D BALDOR 1.5HP 180VDC B5 Permanent Magnet Metric Motors include SCR Drive Motors for replacement on machinery requiring metric mounting dimensions.Part Number:
VP3575DModel/Spec Number:
35P466Z164Manufacturer:
ABB/BaldorTechnical Details
Specifications
Application | General Purpose |
Output HP | 1.5 |
Output KW | 1.1 |
Output RPM | 1750 |
Frame IEC | D90D |
Mount NEMA | With Base |
Documentation
Additional Information
BALDOR DC Permanent Magnet DC Motors are available with a choice of IEC B5 flanges in .2 to 5 HP or B14 C-faces in .2 to 2 HP. All are designed for 180 volt input power with a 20:1 constant torque speed range. These metric frames are designed for replacement on equipment requiring an IEC interface with the gearbox.
APPLICATIONS: include SCR Drive Motors for replacement on machinery requiring metric mounting dimensions.
- B5 Metric flange with B3 foot mounting
- Bolt on non-metric base
- Class F Insulation
- Tach adaptable except type 15kW
- 20:1 constant torque speed range
- Conforms to IEC 60034-1
