FX2-04-B7-140TC BALDOR 4:1 RATIO MULTIPLIER SPEED REDUCER GCF4X02BB
FX2-04-B7-140TC BALDOR 4:1 RATIO MULTIPLIER SPEED REDUCER GCF4X02BB
Picture is for reference only.
Part Number:
GCF4X02BBManufacturer:
Baldor Obsolete GearManufacturer Part Number:
FX2-04-B7-140TCClick below to request an agent review potential options.
Shipping Details
Weight:
29 lbsDimensions:
14 x 14 x 14 inchesHS Code:
8483.00.0000Technical Details
Specifications
Design: | Ratio Multiplier |
Output RPM@1750: | 438 |
Output Torque (lb-in): | 885 |
Max Input HP @1750: | 6.36 |
Ratio: | 4:1 |
NEMA Input Config: | 143-5TC / 0.875" |
Input Config: | FX2 |
Output Config: | Solid Shaft |
Output Shaft "Inch": | 0.875" |
Housing: | Cast Iron |
Documentation
Additional Information
APPLICATIONS: Can reduce or increase input speed when combined with right angle units for high ratios. 4 ratios available. Interchangeable with Grove TX/TXQ series. Custom style "SX" can be back driven in increase motor speed. Max output speed, 4500 RPMS.
FEATURES:
- High efficiency
- Cast iron construction
- Universal mounting positions
- Optional base mounting
- Internal compression chamber eliminates breather vent
- Shipped with synthetic oil
- Lubricated for life with Klubersynth GH6-150
