EM7047T BALDOR 7.5HP EXPLOSION PROOF SUPER-E MOTOR 37H239L864G1

7.5HP BALDOR 1770RPM 213T XPFC 3PH EXPLOSION PROOF SUPER-E MOTOR EM7047T

Part Number:

EM7047T

Model/Spec Number:

37H239L864G1

Manufacturer:

Baldor Obsolete Motors

EM7047T BALDOR 7.5HP Premium Efficient Motor is ideal for use where hazardous fumes or dust may be present.

Item Discontinued

Click below to view suggested functional replacement.

See Replacement Item

Shipping Details

Weight:

161 lbs

Dimensions:

14 x 33 x 19 inches

HS Code:

8501.52.4000

UPC:

781568538333

Technical Details

Specifications

Brand:	Baldor
Application:	Explosion Proof
Output HP:	7.5//5
Output KW:	5.5
Output RPM:	1170//1475
Frame Size NEMA:	213T
Mount NEMA:	With Base
Enclosure NEMA:	XPFC
Voltage:	230/460//190/38
Frequency (Hz):	60//50

Documentation

EM7047T-InfoPacket

Explosion-Proof-Definitions

Additional Information

APPLICATIONS: Ideal for wide variety of applications where hazardous fumes or dust may be present.

FEATURES:

Rolled Steel frame
U.L. and CSA approved for Class I, Group D, Class II, Group F & G, T3C
Available in 182T through 449T frames (-c models)
Corrosion resistant epoxy finish
U.L. approved cast conduit box standard
1.00 Service Factor
EM Super-E® explosion proof motors have NEMA premium efficiency and 3 year warranty.

CAUTION: Explosion-proof motors have a tight fit between mating parts to ensure the integrity of the explosion-proof enclosure. This can lead to an accumulation of moisture inside the motors due to condensation. Care should be used when selecting an explosion-proof motor, especially when installed outdoors and on intermittent duty. Consider Drill Rig Duty Explosion-proof motors for outdoor applications. These explosion-proof motors are not suitable for use with adjustable speed drives "VFD", inverter duty explosion-proof motors must be used.
