Product Overview

EM7014 BALDOR 1HP Explosion Proof Motor is ideal for hazardous location applications driving pumps, compressors, blowers, fans, and many other loads that require hazardous location protection.

Part Number:

EM7014

Manufacturer:

Baldor

Manufacturer Part Number:

35E356M492G1

Technical Details

Specifications

Brand	Baldor
Application	Explosion Proof
Output HP	1
Output KW	0.75
Output RPM	1760//1460
Frame Size NEMA	56

Documentation

Product Information Packet

Explosion-Proof-Definitions.pdf

Additional Information

APPLICATIONS: Ideal for wide variety of applications where hazardous fumes or dust may be present.

FEATURES:

U.L. and CSA approved for Class I, Group D, Class II, Group F & G, T3C
5/8" Keyed output shaft
Corrosion resistant epoxy finish
U.L. approved cast conduit box standard
1.00 Service Factor
EM Super-E® explosion proof motors have NEMA premium efficiency and 3 year warranty.

CAUTION: Explosion-proof motors have a tight fit between mating parts to ensure the integrity of the explosion-proof enclosure. This can lead to an accumulation of moisture inside the motors due to condensation. Care should be used when selecting an explosion-proof motor, especially when installed outdoors and on intermittent duty. Consider Drill Rig Duty Explosion-proof motors for outdoor applications. These explosion-proof motors are not suitable for use with adjustable speed drives "VFD", inverter duty explosion-proof motors must be used.
