3/4HP BALDOR 1755RPM 56 TEFC 1PH SUPER-E MOTOR EL3507

3/4HP BALDOR 1755RPM 56 TEFC 1PH SUPER-E MOTOR EL3507


Part Number:

EL3507

Model/Spec Number:

35E008L999G1

Manufacturer:

ABB/Baldor
EL3507 BALDOR 3/4HP Single Phase Premium Efficient Super-E Motor is used with energy saving applications where continuous or frequent duty is required.
MSRP: $1,179.00

Regular Price

USD

$

861

46

QTY
Login to View Discounts

Free No Rush Shipping

Weight:

44 lbs

Dimensions:

17 x 22 x 16 inches

HS Code:

8501.40.4040

UPC:

781568138618

Technical Details

Application:

General Purpose

Output HP:

3/4

Output KW:

0.56

Output RPM:

1755

Frame NEMA:

56

Mount NEMA:

Base Mount

Enclosure NEMA:

TEFC

Enclosure IEC:

IP44

Voltage:

115/208-230

Frequency (Hz):

60

EL3507-InfoPacket

APPLICATIONS: Typical applications include operations where continuous or frequent duty is required. Super-E single phase motors are designed to conserve energy over extended time periods.

FEATURES:

  • Low-loss electrical grade lamination steel
  • Heavy gauge steel frames
  • ISR® (Inverter Spike Resistant) copper windings
  • Three-year warranty
